Tuya WIFI bluetooth Smart Socket LS-S1

Product parameters:

US standard 10A, 16A, 20A;

Rated voltage: AC100-240V

Rated maximum power: 110V area 1000W/10A and 1300W/20A or less, 220V area 2000W/10A and 3000W/20A or less, due to the high temperature
resistance of the shell, it is not suitable for high-power equipment,
please do not overload.

Product size: 54*54*51mm

Weight: 0.07kg

European standard 16A

 Product size: 50*50*84mm

Weight: 0.09kg

British standard 16A

Product size: 58*58*55mm

Weight: 0.08kg

Input voltage: AC100-240V 50/60Hz

WIFI standard: 2.4GHz 802.11 b/g/n

Indicator light: Blue light indicates switch and network distribution

Shell material: PC+ABS fireproof grade V0

Working temperature: -20-50℃

Certification standard: CE/ROHS

Tuya Smart or Smart Life APP can be connected to WiFi router for mobile phone
remote control. Support Alexa, Google Home, Tmall Genie Xiaoai and other intelligent voice control. Mobile phone APP remote control, intelligent timing, intelligent scene
linkage,power statistics, sharing control

APP network configuration operation steps A. One-click configuration

1. Please connect the mini socket to the power supply and wait for the blue
   indicator light to flash quickly, or press and hold the power button for
   5 seconds until the blue indicator light flashes quickly
   (flashes twice per second)
2.  Connect the phone to wifi and confirm success.
3.  Open the APP, click the add icon in the upper right corner of the device list,
   and select "Socket" to enter the device configuration interface.
4.  Click "Please confirm that the indicator light is flashing quickly",
   enter the password of the WIFI currently connected to the mobile phone,
   and click "Confirm".
5. Wait for configuration. After the configuration is successful,
   click "Finish" to jump to the socket function interface.

   2.AP configuration AP configuration is an auxiliary configuration method.
   If one-key configuration fails, you can use AP configuration.
   The method is as follows:
6. Press and hold the power button for 5 seconds, and the indicator light
   will flash slowly (2 seconds on and 2 seconds off).
7.  Open the APP, click the add icon in the upper right corner of the device list,
   select "Socket" to enter the device configuration interface,
   and click "Compatibility Mode" in the upper right corner to enter
   the AP configuration interface.
8. Click "Please confirm that the indicator light is flashing slowly",
   enter the password of the WIFI currently connected to the mobile phone,
   and click "Confirm".
9.  Click "Go to connect" to jump to the WIFI list interface, select
   SmartLife-XXXX and click "Connect".
10.  Click the return button on the phone and wait for configuration.
    After the configuration is successful, click "Finish" to jump to
    the socket function interface.
